Deye 600w-800w Micro Inverter SUN600/800/1000G3-US-220/EU-230

Short Description:



Model Number: SUN600/800/1000G3-US-220/EU-230
Input Voltage: 60V
Output Voltage: 240V
Output Current: 2.17-4A
Output Frequency: 50Hz/60Hz
Output Type: Single
Size: 185*161*29 mm mm
Type: DC/AC Inverters
Inverter Efficiency: 99%
Certificate: EN50549,VDE0126,VDE4105,IEC62109,CE,INMETRO
Warranty: 10years
Weight: 3.15kg


Product Detail

Product Tags

ABOUT

Main Product

Rechargeable battery, lithium ion battery, lipo battery and LiFePO4 battery. They're used in energy storage system and electric mobility products.

Protect Function

We assemble the battery with PCM/BMS which protection batteries from over-charge,over-discharge,over-current,short-circuit and high

Payment Term

Our payment term is usually 30% deposit before production and 70% balance before shipment. Other requirements also can negotiate.

Customization

Yes, we can support. Please inform us formally before our production and confirm the design firstly based on our sample.

+
Years Of Experiences
+
Professional Experts
+
Talented People
W+
Happy Clients

Deye 600w-800w Micro Inverter SUN600/800/1000G3-US-220/EU-230



Model SUN600G3-US-220 SUN600G3-EU-230 SUN800G3-US-220 SUN800G3-EU-230 SUN1000G3-US-220 SUN1000G3-EU-230
Input Data (DC)
Recommended input Power (STC) 210~400W (2 Pieces) 210~500W (2 Pieces) 210~600W (2 Pieces)
Maximum input DC Voltage 60V
MPPT Voltage Range 25~55V
Full Load DC Voltage Range (V) 24.5~55V 33~55V 40~55V
Max. DC Short Circuit Current 2*19.5A
Max. input Current 2*13A
No.of MPP Trackers 2
No.of Strings per MPP Tracker 1
Output Data (AC)
Rated output Power 600W 800W 1000W
Rated output Current 2.7A 2.6A 3.6A 3.5A 4.5A 4.4A
Nominal Voltage / Range (this may vary with grid standards) 220V/0.85Un-1.1Un 230V/0.85Un-1.1Un 220V/0.85Un-1.1Un 230V/0.85Un-1.1Un 220V/0.85Un-1.1Un 230V/0.85Un-1.1Un
Nominal Frequency / Range 50 / 60Hz
Extended Frequency/Range 45~55Hz / 55~65Hz
Power Factor >0.99
Maximum units per branch 8 6 5
Efficiency 95%
Peak Inverter Efficiency 96.50%
Static MPPT Efficiency 99%
Night Time Power Consumption 50mW
Mechanical Data
Ambient Temperature Range -40~65℃
Size (mm) 212W×230H×40D (Without mounting bracket and cable)
Weight (kg) 3.15
Cooling Natural cooling
Enclosure Environmental Rating IP67
Features
Compatibility Compatible with 60~72 cell PV modules
Communication Power line / WIFI / Zigbee
Grid Connection Standard EN50549-1, VDE0126-1-1, VDE 4105, ABNT NBR 16149, ABNT NBR 16150, ABNT NBR 62116,
RD1699, UNE 206006 IN, UNE 206007-1 IN, IEEE1547
Safety EMC / Standard UL 1741, IEC62109-1/-2, IEC61000-6-1, IEC61000-6-3, IEC61000-3-2, IEC61000-3-3
Warranty 10 years
